ICCO03AW2 1 SPDT On-On 360 Degree CW/CCW Maintained Non Key Retained
Couldn't load pickup availability
Full Details
SWITCH TYPE
SPDT
(Single pole - Double Throw)
IP67 WATERPROOF
12" Wire Length
CONTACT RATING
5a 125/250v AC, .5a 30v DC
SWITCH ACTION
Momentary
on-on
FINISHES
BHMA 626
KEY ROTATION
45 DEGREE ROTATION DETENT- On
KEY RETAINED
PANEL MOUNT PREPARATION
Large Cam Lock Style
1-5/16"dia by .950 (flat width) Double "D" Design
APPLICATION T1 (3 switch)
ETI model AW2/AWJ2 Inter-changeable Core Key Switch Controls will integrate into systems performing the Switch Action
Maintained On-On with 360° clockwise Rotation with SPDT Switch IP67 Waterproof Rating Contact Rating 5a 125/250v AC, 0.0.5A 30v DC.
12" wire length for control applications in Shunting, Activating or Deactivating Control.
