ICCO03C2DG 1 DPST On-On 2 o'clock CW Maintained Non Key Retained
Couldn't load pickup availability
Full Details
SWITCH TYPE
DPST
(Double pole - Double Throw)
Rocker Switch
CONTACT RATING
30A-120-277v AC
Commercial
Light Switch
SWITCH ACTION
Maintained
on-off
MOUNTING
4" Raised Steel Faceplate
Surface Mount Box
2 1/8" deep w/Knockouts
KEY ROTATION
30 Degrees-Clockwise-On
30 Degrees-Counterclockwise -OFF
NON KEY RETAINED
PANEL MOUNT PREPARATIONS
Large Cam Lock Style
1-5/16"dia by .950 (flat width) Double "D" Design
APPLICATION C2DG
ETI model TC2DG Inter-changeable Core Key Switch Controls will integrate into systems performing the Switch Action
30 Degrees-Clockwise - 30 Degrees Counter clockwise with DPST Rocker Switch, 30a 125-277v AC.
Suitable for control applications in shunting, activating, or deactivating control.
